Construction fence for foundation pit guardrail
| Parameter | Common Range |
|---|---|
| Panel Height | 1.2 m, 1.5 m, 1.8 m (standard: 1.2 m) |
| Panel Width | 2.0 m, 2.5 m, 3.0 m (standard: 2.0 m) |
| Frame Tube Thickness | 1.2 mm – 2.0 mm (typical: 1.5 mm) |
| Wire Diameter | 3.0 mm – 4.0 mm |
| Mesh Size | 50×50 mm, 75×75 mm, 100×100 mm |
| Post Size | 40×40 mm / 50×50 mm square tube |
| Post Height | 1.3 m – 1.9 m (matches panel height + ground embedment) |
| Base Weight | 5–15 kg (for free-standing installation) |
The construction fence of foundation pit guardrail (also known as edge protection fence) is a movable rigid protective facility specially designed for high-risk areas such as building foundation pits, openings, and floor edges. Its core function is to prevent accidental falls of personnel, vehicles, and materials through physical isolation, and to serve as a safety warning. It is a key equipment for safe, civilized, and standardized construction.
Core features: protection, prominent warning, flexible and practical
Mandatory physical isolation: using a sturdy metal structure to form a rigid barrier of up to 1.0-1.2 meters, effectively blocking personnel from approaching dangerous edges and preventing falling accidents.
Eye catching visual warning: using yellow (red) and black or red and white universal warning colors, and often equipped with warning lights and reflective strips, it can have a strong warning effect both during the day and at night.
Modularity and flexibility: Standard modular design (such as 1.2m x 2.0m), with one-to-one connectors that can be assembled, disassembled, and reused at a suitable speed. The bottom can be equipped with an adjustable base or universal wheels, making it easy to move and deploy on different construction sites and locations.
Stable and excellent: The overall structural design has good resistance to impact and tipping. Fixed to the ground with expansion bolts or using a counterweight base (such as a cement pier or water tank) to achieve stable placement.
Civilized construction image: Standardized, neat, and aesthetically pleasing enclosures reflect the standardized management level of the construction unit and enhance the overall image of the construction site.
